Flora C25h Pro
Flora C25h Pro

600dpi, 4 level grayscale, DOD


Intelligent modular system, on-line upgrading of printer configuration

to meet productivity


Low consumption, minimum maintenance, low cost


The industry's first automatic adjustment paper width, paper height

with patting function

Download PDF

  • Data sheet
  • Features

Print Technology

Print headPiezoelectric inkjet technology(DOD), 4 level grayscale
ResolutionMax 600×1200dpi
ProductivityDraft mode：1200㎡/hr
Express mode：600㎡/hr
Production mode：400㎡/hr
Quality mode：300㎡/hr
Inks
Ink TypeAQ ink
Color OptionCMYK
Ink Tank Capacity5L/C
Media Handle
Material transferStrong vacuum table, Industrial belt transmission
Max. Media size

Standard size: 2500 × 1500mm

Max.size: 2500 × 4000mm (custom brackets required)

Thickness1.5-20mm (Printer supports media thickness<50mm)
Max. Print widthMax. 2500mm
Feeder&Stacker
Auto feeding size500mm-2500mm
Auto stacking size< 2500mm(Optional)
RIP/ Data Interface
Data InterfaceUSB 3.0
RIP
Photoprint /Onyx, open for the third part RIP
Dimension & Weight
Machine5300 × 3950 × 1820mm，5500kg
Printing Unit5500 × 2180 × 2240mm，3800kg
Feeder4500 × 1450 × 2140mm，2800kg
Stacker3400 × 1780 × 1800mm，1500kg
Operation Condition
EnvironmentLow dust, less light
Temperature20-35℃，(ideal condition)
Relative humidity50%~70%(ideal condition)
Installation Requirements
Power supplyAC380-400V，3 Phase，40A，50/60Hz，15kW
Compress airDry compressed air，6-8 bar
Warranty

One year (Please consult your local deler for details)

*the final specification of the machine is subject to actual product. Please contact the sales manager for the latest specification data.

*The company reserves the right of final interpretation of this brochure.










-Three rows of print heads, multiple configuration

  • Standard CMYK, satisfy most of customer's request

  • Support online upgrade, configuration upgrade from economy version to high-speed version


-Automatic cleaning & moisturizing system

  • Automatic cleaning system, simple and convenient maintenance

  • Automatic moisturizing system, greatly reduce the maintenance times of print head，improve production efficiency


-Industrial belt conveyor, vacuum adsorption

  • Industrial belt conveyor, strong vacuum suction, greatly ensure the smoothness of the sbustrates

  • Ensure paper feeding accuracy to feed evenly


-Auto-stacker system(optional)

  • Automatic stacker system

  • Max. media size up to 2500×1350mm


-Friendly GUI, easy operation

  • PLC real-time displays the printer status

  • The friendly GUI is easy to learn and operate, able to calculate the ink volume for each printing job


-Auto-feeder

  • Automatic feeding system, save labor, increase productivity

  • Max. media size up to 2500×1500mm
